Battery charger an tester curatio®
Universal Battery Adapter Typ 4
With the test pins on the adapter a variety of battery types can be contacted at the
Battery Tester and Charger curatio, charged and discharged.
Each of the test pins can be moved in any direction and
be fixed by a locking nut.
Universal battery adapter for four battery packs
Article-No. 31008
Dimensions:
Bottom plate 240,0 x 195,0 mm,
Contact gap + Battery to - battery 10.5 to 75.0 mm
Distance from bottom plate to contact pins max. 140 mm
Universal battery adapter for one battery packs
Article-No. 31009
Dimensions:
Bottom plate 195,0 x 125,0 mm,
Contact gap + Battery to - battery 10.5 to 75.0 mm 10,5 to 75,0 mm,
Distance from bottom plate to contact pins max. 135 mm
